Drivetech 12V Control Box 5 Rocker Switches 3 Power Sockets Dual USB
Complete easy-to-fit wiring solution for 4x4’s, camper trailers and caravans.
Includes auto reset circuit breakers to eliminate the need to carry fuses, and features multiple positive and negative input/output studs.
With easy to follow fitting and wiring instructions, the control box is compatible with a wide range of DC-DC’s and solar regulators.
SPECIFICATIONS
- Laser cut powder coated alloy case (2mm top, 1.5mm case)
- 6x Automatic re-settable circuit breakers 2x 25A on Anderson style plugs,
- 4x 15A for switches and power/USB sockets
- 1x 29mm Round voltmeter
- 3x 29mm Round power sockets (20A maximum)
- 1x 29mm Round dual USB sockets (1x 5V 2.4A, 1x 1A)
- 2x Anderson plugs with circuit breakers
- 5x Switches with sticker kit (10A maximum)
- Mounting points for DC-DC charger
- 1x Negative busbar
- 2x Positive 8mm studs
- 1x Negative 8mm stud
- 4x 25mm Entry grommets (1 per side)
- Box dimensions 400x250x80mm
- 12 Month warranty
SKU: DT-02009
Additional information
Weight | 2 kg |
---|---|
Dimensions | 25 × 25 × 25 cm |
